UK 16N Din Rail Terminal Block

A key application is inside automation control cabinets, where these blocks are used to neatly terminate and manage wiring from PLCs, servo drives, frequency converters, and similar equipment. This organized approach not only secures connections but also creates a logical layout that eases troubleshooting and system updates.

Should you require a reliable and economical terminal solution for your projects, our team is ready to assist. We invite you to reach out to our team to learn more about how our products can meet your needs.

Product Introduction

When you're specifying components for industrial power distribution, you need parts that won't just meet the spec sheet but hold up under real-world stress. That’s the thinking behind our CHTAR UK 16N Din Rail Terminal Block. Electrically, it’s built to handle the demands: an 800V withstand voltage and a solid 76A current capacity (given a 40°C ambient and 16mm² wire) cover a lot of ground. And for safety, its insulation is validated through a rigorous 3000V power frequency test—a fundamental check we know matters.

Mechanical reliability is where you separate good components from great ones. Take wire retention: the pull-out force on a 10mm² conductor is tested to far exceed 100N, so vibrations on the factory floor won't loosen it. Perhaps just as critical, the clamp that locks it onto the DIN rail has been proven through sweep frequency vibration testing (10-55Hz). This means once you snap the UK 16N Din Rail Terminal Block into place, it stays put—no accidental derailment during transport or operation. It’s a small detail with huge implications for long-term field reliability. That’s the kind of foresight built into every UK 16N Din Rail Terminal Block.

We built it to last. The housing uses flame-retardant, V-0 rated PA66. Conductive parts undergo a 48-hour salt spray test to fight corrosion, and it operates reliably from -40°C to +120°C What you see here comes from real validation testing—the kind that proves long-term stability under pressure. For a robust connection in tough conditions, the UK 16N Din Rail Terminal Block is engineered to deliver, reliably, across multiple projects. When you choose it—when you choose the UK 16N Din Rail Terminal Block—you're choosing performance you can count on, day after day, installation after installation.

Product Parameter (Specification)

Product Application

UK 16N screw Din Rail Terminal Block is using universal mounting feet (compatible with U-rail NC35 or G-rail NC32), the rail terminals can be securely fastened to control cabinet rails, preventing loosening while providing multi-wire support and hot-swap functionality (select models). This design accommodates scenarios with limited space.

Quality Control

Our quality control team employs various inspection methods—including patrol inspections and 100% inspections—at different stages throughout the production process to manage all quality issues. We strictly control and prevent any quality risks during production.

Customer

Our company has been engaged in the terminal block industry for many years and maintains long-term, stable partnerships with established clients. Our products are exported worldwide, reaching markets beyond China to countries across Europe, South America, Southeast Asia, and beyond.
